XRCHH26M000F1QD8P0|26MHz|2520mm|-30~85°C

產品簡介

XRCHH26M000F1QD8P0|26MHz|2520mm|-30~85°C ,XRCHH26M000F1QD8P0晶振,頻率26MHz,尺寸2520mm,工作溫度-30~85°C,數碼相機晶振,無線通訊設備晶振,超小體積貼片晶振,藍牙音響耳機晶振,電腦主板晶振,網絡終端晶振.

產品詳情

CT-1

XRCHH26M000F1QD8P0|26MHz|2520mm|-30~85°C,XRCHH26M000F1QD8P0晶振,頻率26MHz,尺寸2520mm,工作溫度-30~85°C,數碼相機晶振,無線通訊設備晶振,超小體積貼片晶振,藍牙音響耳機晶振,電腦主板晶振,網絡終端晶振.

高端數碼電子諧振器,8045陶瓷殼2P晶振,NX8045GE晶振

XRCHH26M000F1QD8P0|26MHz|2520mm|-30~85°C

型號	TAS-2520F
頻率	26.0000MHz
頻率公差	±10ppm max.(25±3℃)
工作溫度范圍	-30℃ to 85℃
頻率溫度特性	±15ppm max.
頻率老化	±1ppm max./year
清洗	Notavailable
負載電容量	8pF
等效串聯電阻(max.)	60Ω
驅動電平(max.)	60μW
形狀	SMD

XRCHH26M000F1QD8P0|26MHz|2520mm|-30~85°C

原廠編碼	型號	頻率	頻率公差	頻率溫度特性	負載電容量	工作溫度
XRCHH16M000F1QB7P0	TAS-2520F	16.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH20M000F1QB1P0	TAS-2520F	20.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH26M000F1QD8P0	TAS-2520F	26.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH36M000F1QA3P0	TAS-2520F	36.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH27M000F1QB3P0	TAS-2520F	27.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH28M000F1QB3P0	TAS-2520F	28.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH29M000F1QB3P0	TAS-2520F	29.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH30M000F1QB3P0	TAS-2520F	30.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH31M000F1QB3P0	TAS-2520F	31.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH32M000F1QB3P0	TAS-2520F	32.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH33M000F1QB3P0	TAS-2520F	33.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH34M000F1QB3P0	TAS-2520F	34.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH35M000F1QB3P0	TAS-2520F	35.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH42M000F1QB3P0	TAS-2520F	42.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH37M000F1QB3P0	TAS-2520F	37.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH38M000F1QB3P0	TAS-2520F	38.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH39M000F1QB3P0	TAS-2520F	39.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH40M000F1QB3P0	TAS-2520F	40.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH48M000F1QB3P0	TAS-2520F	48.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
XRCHH52M000F1QA2P0	TAS-2520F	52.0000MHz	±10ppm max. (25±3℃)	±15ppm max.	8pF	-30℃ to 85℃
